Flange Locknut M10 (10mm) x 1.5mm Nut Serrated Mild Steel MS Zinc Plated
Serrated Flange Locknuts have serrations on the underside of the flange preventing the nuts from loosening. Also known as collar nuts, they do not require a washer. Instead, the flange spreads the holding force across a wide area.
Product Code/SKU:
15033
This product is currently not longer available for ordering. This page is made available for information only.
Specifications
Specifications for Flange Locknut M10 (10mm) x 1.5mm Nut Serrated Mild Steel MS Zinc Plated
Material
Mild Steel
Thread Pitch
1.5 mm
F-Flange Width
19.5 mm
H-Height
9 mm
Thread
10mm M10 mm
W-Width
14 mm
T-Flange Thickness
3 mm
| P.Code | Material | Thread mm |
Thread Pitch mm |
W-Width mm |
F-Flange Width mm |
T-Flange Thickness mm |
H-Height mm |
|---|---|---|---|---|---|---|---|
| 15033 | Mild Steel | 10mm M10 | 1.5 | 14 | 19.5 | 3 | 9 |
