Wing Nut M5 (5mm) 0.8mm Pitch Mild Steel MS Zinc Plated
These nuts have wings that provide more leverage for greater torque while manual tightening. Quick and easy assembly by hand. Commonly used in applications where the Fastener is often adjusted or frequently removed.
Product Code/SKU:
15026
This product is currently not longer available for ordering. This page is made available for information only.
Specifications
Specifications for Wing Nut M5 (5mm) 0.8mm Pitch Mild Steel MS Zinc Plated
Material
Mild Steel MS
Thread Pitch
0.8 mm
W-Width
22 mm
Thread
5mm M5 mm
H-Height
11 mm
D-Base
9.25 mm
| P.Code | Material | Thread mm |
Thread Pitch mm |
H-Height mm |
W-Width mm |
D-Base mm |
|---|---|---|---|---|---|---|
| 15026 | Mild Steel MS | 5mm M5 | 0.8 | 11 | 22 | 9.25 |
